Description
SPEC
| body shape | AEWC body |
| top | Spruce top |
| back & sides | Maple Burl back & sides |
| bracing | X Bracing |
| neck | Mahogany neck |
| fretboard | Rosewood |
| bridge | Rosewood |
| body binding | Black |
| back strip inlay | Black |
| soundhole rosette | Rosewood rosette |
| tuning machine | Black Die-cast tuners |
| number of frets | 20 |
| bridge pins | Ibanez Advantage™ bridge pins |
| strings | Ibanez IACS6C coated strings |
| pickup | Fishman® Sonicore pickup |
| preamp | Ibanez AEQ-SP2 preamp w/Onboard tuner |
| output jack | Balanced XLR & 1/4″ outputs |
| battery | 9V Battery |
| finish top | Satin |
| finish back and sides | Satin |
| finish neck back | Satin |
NECK DIMENSIONS
| Scale : | 634mm |
| a : Width | 43mm at NUT |
| b : Width | 55mm at 14F |
| c : Thickness | 20mm at 1F |
| d : Thickness | 21mm at 7F |
| Radius : | 400mmR |
BODY DIMENSIONS
| a : Length | 19 1/4″ |
| b : Width | 15″ |
| c : Max Depth | 4″ |
RECOMMENDED CASE/BAG
- AEG10C
