Description
Kosmos® v2 Spectrum Enhancement System
The Kosmos® v2 is a second generation subharmonic and stereo image enhancement system. As the successor to the awardwinning Kosmos®, it incorporates improved circuitry and adds features to provide even more functionality for live sound and
recording applications. Like the original Kosmos®, it can provide planet rattling bass as its subharmonic processor watches the
source material, analyzes the bass, then generates additional phase-synced low frequencies an octave below it. Borrowing from
the Kosmos® Pro, the damping (tracking) has two preset ranges.
When using the Kosmos® v2, it is recommended that other equalization (especially output equalization) be set flat. Adjust the
Kosmos® v2 to optimize the tone quality, then make any fine adjustments with the other gear. You may find that little needs
to be tweaked, since the Kosmos® v2 corrects deficiencies in the speaker system. Bass boost applied before the Kosmos® v2
may defeat what you are trying to accomplish by causing the sound to be muddy or distorted.
Peavey Kosmos 2 Features:
- Subharmonics, Low Freq, High Freq, Output Level and Sub Output Level
- Creates intelligent, phase-synced subharmonics that don’t overpower existing material
- Damping control
- Dynamic source tracking yields tight, clean bass sounds
- Subharmonic activity indicator shows processing status
- A specially tuned low frequency circuit compliments the subharmonics and can be used to fatten the low end
- High frequency image enhancement provides atmosphere through improved stereo separation and clarity
- A rear panel stereo/mono switch allows use as a channel insert or in a monophonic system
- Crossover Disable – Internal 90 Hz crossover signal can be removed from the subwoofer output when used as a side-chain effect
- Cut Subs From Main switch
- Master output level controls left, right, and subwoofer output levels simultaneously
- Dual XLR and 1/4″ TRS I/O – All inputs & outputs are balanced XLR or 1/4″ TRS jacks.
- Mono Sum switch on outputs
- Signal and Peak lamps monitor signal activity and warn of overload
- Independent subwoofer output level control
- TRS-balanced Sub output
- Single rack space
USER MANUAL: https://assets.peavey.com/literature/manuals/KosmosII.pdf
